| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 1 | LIT3397618 | Literature Parts (instructions, Installation) |
|
- | |||||
| 1 | LIT8318480 | Literature Parts (guide, Use & Care) |
|
- | |||||
| 1 | LIT3979703 | Literature Parts (label, Wiring Diagram) |
|
- | |||||
| 2 | WP681414 | Screw,10-16 X 1/2 (Replaces: 343641) |
|
Immediately | $ 7.62 | ||||
| 3 | WP693995 | Screw 8-18 X 3/8 (Replaces: 693995) |
|
Immediately | $ 6.80 | ||||
| 5 | W11539855 | Cover, Block (Replaces: 3396795) |
|
Immediately | $ 566.78 | ||||
| 6 | 342043 | Screw, 10-32 X 3/8 |
|
- | |||||
| 7 | 280043 | Panel, Rear (Replaces: 3396805) |
|
$ 322.53 | |||||
| 8 | 692989 | Dry Rack Bracket |
|
$ 12.77 | |||||
| 10 | WP3406107 | Door, Switch Assembly (Replaces: 3406107) |
|
Immediately | $ 28.08 | ||||
| 11 | WP3395530 | Screw, 6-20 X 7/8 (Replaces: 697773) |
|
$ 7.71 | |||||
| 12 | 3406839 | Dry Rack |
|
Immediately | $ 59.11 | ||||
| 13 | WP308685 | Screw,10-16 X 1/2 (Replaces: 3357011) |
|
Immediately | $ 7.08 | ||||
| 14 | WPW10041960 | Spring, Door (2) (Replaces: 692495) |
|
Immediately | $ 38.43 | ||||
| 15 | W10854425 | Clip, Front Panel (2) (Replaces: 3394083) |
|
Immediately | $ 14.71 | ||||
| 16 | 49621 | Foot, Dryer (Replaces: 3392100) |
|
Immediately | $ 7.70 | ||||
| 16 | 49621 | Foot - Optional (extended Length Package Of 2 ) (not Included) (Replaces: 279810) |
|
Immediately | $ 7.70 | ||||
| 17 | 279318 | Terminal, Tinned & Brass (3) (includes Illus. 39) |
|
Immediately | $ 95.44 | ||||
| 18 | 8533643 | Cabinet (Replaces: 8530603) |
|
$ 377.30 | |||||
| 19 | WP98234 | Clip, Ground (Replaces: 98234) |
|
Immediately | $ 10.76 | ||||
| 20 | WP18776 | Lock, Front Top (2) (Replaces: 690363) |
|
Immediately | $ 11.98 | ||||
| 21 | 279443 | Panel, Front (Replaces: 695620) |
|
$ 364.96 | |||||
| 23 | 279220 | Clip, Felt Pad (3) (Replaces: 685203) |
|
$ 21.20 | |||||
| 24 | WP3389441 | Catch, Door Assembly (Replaces: 3389441) |
|
Immediately | $ 6.56 | ||||
| 26 | W11252547 | Clip, Hinge (2) (Replaces: 337189) |
|
$ 20.21 | |||||
| 27 | WP694091 | Screw, 8-18 X 3/8 (Replaces: 694091) |
|
$ 6.80 | |||||
| 28 | WP8066056 | Hinge, R.h. (Replaces: 8066056) |
|
Immediately | $ 93.02 | ||||
| 28 | WP8066057 | Hinge, L.h. (Replaces: 8066057) |
|
$ 90.86 | |||||
| 33 | 279570 | Strike, Door (Replaces: 696144) |
|
Immediately | $ 8.00 | ||||
| 35 | WP695737 | Door, Rear (Replaces: 695737) |
|
$ 240.56 | |||||
| 36 | WP3393549 | Door, Front (Replaces: 3393549) |
|
$ 166.81 | |||||
| 37 | WP348721 | Handle, Door (Replaces: 690270) |
|
$ 73.60 | |||||
| 38 | W11035878 | Seal & Bearing Assembly (Replaces: 3406129) |
|
Immediately | $ 83.41 | ||||
| 39 | 279393 | Terminal Block Kit (for Terminal Block) |
|
Immediately | $ 50.09 | ||||
| 40 | W10850756 | Screw, 10-32 X 5/8 (Replaces: 697776) |
|
$ 7.38 | |||||
| 41 | WP3397659 | Block, Terminal (Replaces: 3397659) |
|
$ 21.75 | |||||
| 51 | WP8066217 | Hinge, Top (2) (Replaces: 238088) |
|
$ 7.39 | |||||
| 53 | WP691366 | Idler & Slide Assembly (Replaces: 3394332) |
|
Immediately | $ 20.22 | ||||
| 56 | 341241 | Belt, Drive (Replaces: 8066065) |
|
Immediately | $ 16.34 | ||||
| 57 | WP348780 | Base, Motor (Replaces: 348780) |
|
Immediately | $ 114.89 | ||||
| 58 | 3400500 | Bolt, 5/16-18 X 3/4 |
|
Immediately | $ 12.64 | ||||
| 59 | WP8066184 | Pulley, 60 Hz. (Replaces: 3394341) |
|
Immediately | $ 45.92 | ||||
| 62 | 279827 | Motor Assembly 60 Hz. (Replaces: 661654) |
|
Immediately | $ 195.48 | ||||
| 63 | WP660658 | Clamp, Motor (Replaces: 660658) |
|
$ 7.40 | |||||
| 64 | WP3404162 | Clamp, Motor (w/shield) (Replaces: 3404162) |
|
Immediately | $ 7.39 | ||||
| 67 | W10906683 | Seal, Door (Replaces: 3390731) |
|
$ 121.46 | |||||
| 68 | WP308685 | Screw, 10-16 X 1/2 (Replaces: 3393008) |
|
Immediately | $ 7.08 | ||||
| LIT677818 | Dryer |
|
- |
