| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 1 | WP12883508SP | Shelf, Glass (Replaces: 12883508SP) |
|
$ 288.57 | |||||
| 2 | WPW10194032 | Glide, Snack Pan Right Hand (Replaces: W10194032) |
|
$ 114.92 | |||||
| 2 | WPW10194031 | Glide, Snack Pan Left Hand (Replaces: W10194031) |
|
$ 118.29 | |||||
| 3 | W11233072 | Screw (Replaces: 12990302SP) |
|
Immediately | $ 13.25 | ||||
| 4 | WPW10319333 | Pan-snack (Replaces: W10319333) |
|
$ 130.46 | |||||
| 6 | W11197490 | Shelf, Mini (stationary) (Replaces: 12885501) |
|
$ 217.85 | |||||
| 7 | 13107112SQ | Door, Pantry (stainless) (Replaces: 13107112S) |
|
$ 914.72 | |||||
| 8 | WPW10443326 | Gasket, Pantry (grey) (Replaces: W10443326) |
|
$ 312.90 | |||||
| 9 | W11402525 | Shelf, Glide Out (Replaces: 12883507) |
|
$ 211.00 | |||||
| 10 | W11093713 | Adapter, Pantry (left Hand) (Replaces: W10495308) |
|
$ 127.30 | |||||
| 10 | W11093714 | Adapter, Pantry (right Hand) (Replaces: W10495309) |
|
$ 124.49 | |||||
| 11 | W10277360 | Gear, Spur |
|
$ 28.67 | |||||
| 12 | W10294414 | Cover, Gear (right Handd) |
|
$ 75.13 | |||||
| 12 | W10284709 | Cover, Gear (left Hand) |
|
$ 66.50 | |||||
| 13 | WPW10272364 | Screw (Replaces: W10272364) |
|
Immediately | $ 10.22 | ||||
| 15 | W10298176 | Shaft-rack |
|
- | |||||
| 16 | W10251968 | Ladder, Side (left Hand) |
|
$ 24.64 | |||||
| 16 | W10251965 | Ladder, Side (right Hand) |
|
$ 27.97 | |||||
| 17 | WPW10277361 | Collar-gear (Replaces: W10277361) |
|
$ 10.88 | |||||
| 18 | WPW10530656 | Pan, Pantry (Replaces: W10268846) |
|
$ 216.79 | |||||
| 19 | W10273464 | Ladder, Center |
|
Immediately | $ 27.17 | ||||
| 21 | 67006425 | Screw (Replaces: 12990513) |
|
Immediately | $ 6.57 | ||||
| 22 | WP67006415 | Screw (Replaces: 12990512) |
|
$ 7.54 | |||||
| 23 | W10285573 | Divider, Pantry |
|
- | |||||
| 25 | W11291138 | Switch-rocker (Replaces: 12466104) |
|
Immediately | $ 33.00 | ||||
| 26 | W11715934 | Rail, Pantry (right Hand) (Replaces: W10311726) |
|
$ 41.24 | |||||
| 26 | W10311723 | Rail, Pantry (left Hand) |
|
$ 127.83 | |||||
| 28 | W10311727 | Rail-rear Pantry |
|
- | |||||
| 29 | WP98165 | Screw (Replaces: 12990521) |
|
$ 7.71 | |||||
| 30 | W10311725 | Cover, Pantry Rail (left Hand) |
|
$ 16.42 | |||||
| 31 | 12227305 | Brace-pantry |
|
- | |||||
| 32 | WPW10296571 | Glass-pantry Shelf (Replaces: W10296571) |
|
$ 222.39 | |||||
| 33 | W10335721 | Harness-rc-led |
|
- | |||||
| 34 | W10223025K | Handle, Snack Pan (stainless) |
|
$ 85.40 | |||||
| 35 | WPW10288153 | Screw (Replaces: W10288153) |
|
Immediately | $ 8.69 |
