01 - Cabinet
02 - Refrigerator Liner
03 - Freezer Liner
04 - Freezer Door
05 - Refrigerator Door
06 - Unit
07 - Air Flow
08 - Control, Lit/optional
SELECT A DIAGRAM
New Model Search:
| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 1 | 1106923 | Refrigerator Door (white) |
|
- | |||||
| 1 | 1108465 | Refrigerator Door (almond) (also Order Item 20) |
|
- | |||||
| 2 | 988402 | Tap Plate |
|
- | |||||
| 3 | 4318165 | Door Closer, Upper Cam (Replaces: 1115905) |
|
Immediately | $ 29.74 | ||||
| 4 | WP489069 | Screw (Replaces: 488938) |
|
Immediately | $ 8.40 | ||||
| 5 | 1115906 | Bracket, Door Stop |
|
- | |||||
| 7 | WP489069 | Screw (Replaces: 488938) |
|
Immediately | $ 8.40 | ||||
| 8 | WP1104787 | Shim, Door Closer (Replaces: 1104787) |
|
$ 7.96 | |||||
| 10 | 1117766 | Gasket Retainer, Side (2) |
|
$ 36.55 | |||||
| 11 | 1118301 | Gasket Retainer, Top & Bottom |
|
- | |||||
| 12 | 2188404A | Door Gasket, Magnetic (Replaces: 2148270) |
|
$ 269.26 | |||||
| 13 | 509929 | Cap, Hinge Sleeve |
|
- | |||||
| 14 | 987009 | Handle |
|
- | |||||
| 15 | 2152266 | Reinforcement, Shelf |
|
- | |||||
| 16 | WP488729 | Screw (Replaces: 487909) |
|
Immediately | $ 8.28 | ||||
| 17 | WP939101 | Screw, Anchor (Replaces: 939101) |
|
$ 7.88 | |||||
| 18 | 489075 | Screw |
|
- | |||||
| 19 | 2148102 | Insert, Handle (white) |
|
- | |||||
| 19 | 2148103 | Insert, Handle (almond) |
|
- | |||||
| 20 | 876029 | Foam Insulation (required When Replacing Exterior Door Panel) |
|
- | |||||
| 21 | 987008 | Insert Retainer (top) |
|
- | |||||
| 22 | 987010 | Insert Retainer (bottom) |
|
- | |||||
| 23 | 987006 | End Cap |
|
- | |||||
| 24 | 2148267 | Trim, Door Shelf (2) |
|
- | |||||
| 25 | 2160049 | Divider, Shelf |
|
- | |||||
| 27 | 1124961 | Interior Door Panel Also Order Item 15 (3) |
|
- | |||||
| 28 | 2148268 | Trim, Door Shelf (2) |
|
- | |||||
| 29 | 4388286 | Retainer, Door Trim (8) (Replaces: 1124877) |
|
$ 16.10 | |||||
| 32 | 2148218 | Door, Compartment |
|
- | |||||
| 36 | 2162781 | Nameplate (white) |
|
- | |||||
| 36 | 2162782 | Nameplate (almond) |
|
- | |||||
| 43 | 1110717 | Trim, Door Compartment |
|
- | |||||
| 44 | WP489069 | Screw, (30) (Replaces: 489101) |
|
Immediately | $ 8.40 |
