03 - Shelf Parts


04 - Refrigerator Door Parts


05 - Unit Parts


06 - Icemaker Parts


07 - Freezer Door Parts


08 - Water Dispenser Parts, Optional Parts


Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	2210522		Shelf, Ladder (2)				$ 44.10
2	2300520		Shelf, Ladder Center				$ 75.36
3	WPW10130299		Cup, Shelf Mtg.   (Replaces: 2163762)			Immediately	$ 13.23
5	WP489478		Screw   (Replaces: 489478)				$ 7.36
6	WP3400065		Screw   (Replaces: 3400065)			Immediately	$ 7.36
7	2214912		Glass, Shelf		Appelez-nous	-
8	2254352A		Ice Bucket   (Replaces: 2254352)				$ 52.78
9	WP2314548		Crisper Cover   (Replaces: 2314497)				$ 233.85
10	2214908K		Shelf Assembly		Appelez-nous	-
11	WP2169921		Glass, Crisper Cover   (Replaces: 2221693)				$ 233.04
12	2214892		Frame Assembly, Meat Shelf		Appelez-nous	-
13	2254458		Deflector-air				$ 68.24
14	2195340		Trim-crisper Pan (10 Inch) (crisper Cover)				$ 7.07
15	WP2172748		Crisper, Support   (Replaces: 2314477)				$ 91.87
16	2214908		Shelf Assembly, Spillguard (2)		Appelez-nous	-
17	2189453		Shelf, Freezer		Appelez-nous	-
18	W10856580		Pan, Crisper Assy. (10 Inch) (includes Illus. 14, 21, 22)   (Replaces: 2218129)			Immediately	$ 159.33
19	W10854037		Pan, Crisper Assy. (13 Inch) (includes Illus. 21,22 & 23)   (Replaces: 2218130)			Immediately	$ 161.27
20	WP2218127K		Pan, Meat   (Replaces: 2218127)				$ 132.12
21	WP2176222		Slide, Crisper   (Replaces: 2176222)				$ 27.35
22	W11819839		Body, Humidity Control   (Replaces: 2212446)				$ 14.23
23	WP2195341		Trim, Crisper Pan (13 Inch)   (Replaces: 2195341)				$ 78.00
24	2176356		Trim, Meat Pan		Appelez-nous	-
