| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 1 | W11117429 | Lint Chute Assembly (Replaces: 348368) |
|
$ 165.38 | |||||
| 2 | 3404332 | 4``- 90~ Elbow (exhaust) |
|
- | |||||
| 4 | WP3388703 | Washer-support (Replaces: 3388703) |
|
$ 7.07 | |||||
| 5 | WP90767 | Screw, 8a X 3/8 (Replaces: 90767) |
|
Immediately | $ 7.43 | ||||
| 6 | WP3392519 | Fuse, Thermal (Replaces: 3392519) |
|
Immediately | $ 22.46 | ||||
| 7 | WP3387134 | Thermostat, Internal Bias (Replaces: 3387134) |
|
Immediately | $ 32.31 | ||||
| 8 | 279816 | Thermal Cutoff (includes Item 15) (Replaces: 3399848) |
|
Immediately | $ 54.64 | ||||
| 9 | W11233063 | Shield, Exhaust (Replaces: 696302) |
|
$ 21.06 | |||||
| 10 | WP694089 | Wheel, Blower (Replaces: 694089) |
|
Immediately | $ 33.89 | ||||
| 11 | WP8577230 | Housing, Blower (Replaces: 3405016) |
|
$ 168.17 | |||||
| 12 | 279771 | Clip (Replaces: 3398161) |
|
$ 13.55 | |||||
| 13 | WP681414 | Screw,10-16 X 1/2 (Replaces: 343641) |
|
Immediately | $ 7.62 | ||||
| 14 | WP8541818 | Box, Heater (Replaces: 3397566) |
|
$ 266.61 | |||||
| 15 | WP3390291 | Thermostat, High Limit 250~f (121.1~c) (60 Hz.) (Replaces: 3390291) |
|
Immediately | $ 85.45 | ||||
| 17 | 279838 | Heater Element (Replaces: 3398063) |
|
Immediately | $ 84.97 | ||||
| 18 | 279457 | Terminal Wire Kit (for Heater Element Wiring Harness Repair) |
|
Immediately | $ 7.13 | ||||
| 19 | WP489463 | Screw, 8-18 X 3/4 (Replaces: 3400800) |
|
$ 7.43 | |||||
| 20 | 3392123 | Seal, Blower |
|
- | |||||
| 23 | W11415783 | Seal, Lint (Replaces: 347139) |
|
Immediately | $ 17.23 | ||||
| 41 | WPW10512946 | Tri Ring (4) (Replaces: 690997) |
|
Immediately | $ 8.71 | ||||
| 42 | WPW10359270 | Shaft, L.h. (Replaces: 3399506) |
|
Immediately | $ 65.44 | ||||
| 43 | WPW10359269 | Shaft, R.h. (Replaces: 3399507) |
|
Immediately | $ 51.09 | ||||
| 44 | WPW10314173 | Support, Roller (Replaces: 3396801) |
|
Immediately | $ 25.65 | ||||
| 46 | WP348197 | Washer, Support (Replaces: 348197) |
|
$ 6.80 | |||||
| 47 | WP3359452 | Nut, 3/8-16 (Replaces: 3359452) |
|
Immediately | $ 6.80 | ||||
| 48 | 3396793 | Bulkhead |
|
- | |||||
| 62 | 279441 | Ring, Bearing (2) (Replaces: 692526) |
|
Immediately | $ 66.11 | ||||
| 63 | WPW10109200 | Screw, 11-16 X 7/8 (Replaces: 97787) |
|
Immediately | $ 7.92 | ||||
| 64 | W11684613 | Bracket, Shaft (Replaces: 3394133) |
|
$ 19.79 | |||||
| 65 | WP90296 | Clip (Replaces: 90296) |
|
$ 7.42 | |||||
| 66 | 279408 | Seal, Rear (Replaces: 347885) |
|
$ 66.22 | |||||
| 67 | W10899578 | Drum Assembly (Replaces: 695587) |
|
$ 337.98 | |||||
| 68 | WP692490 | Baffle, Drum (long) (2) (Replaces: 692490) |
|
$ 150.51 | |||||
| 69 | WP3403636 | Baffle, Drum (short) (1) (Replaces: 3403636) |
|
$ 131.03 | |||||
| 73 | WP339956 | Seal (Replaces: 339956) |
|
Immediately | $ 8.15 | ||||
| 81 | 279366 | Pad, Sensor (Replaces: 348861) |
|
$ 90.58 | |||||
| 83 | WP342267 | Clip, Sensor (2) (Replaces: 342267) |
|
$ 7.33 | |||||
| 90 | WP348859 | Electrode, Inside (Replaces: 348859) |
|
$ 7.54 | |||||
| 91 | WP348860 | Electrode, Outside (Replaces: 348860) |
|
$ 7.61 | |||||
| 92 | WP298877 | Washer, Insulating (Replaces: 298877) |
|
$ 21.34 |
