| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 1 | R0157488 | Kit, Magnetron |
|
- | |||||
| 2 | B5774402 | Brkt-mag Tube |
|
- | |||||
| 3 | B8343706 | Gasket |
|
- | |||||
| 4 | D7292644 | Wire, Jumper |
|
- | |||||
| 4 | D7292672 | Jumper Wire |
|
- | |||||
| 5 | D7292695 | Jumper Wire |
|
- | |||||
| 6 | M0118901 | Clip |
|
- | |||||
| 7 | B5706702 | Fan Blade-blower |
|
- | |||||
| 8 | C8811602 | Motor, Blower, 120 V., 60 Hz, |
|
- | |||||
| 10 | M0118801 | Clip |
|
- | |||||
| 11 | A3030303 | Gasket (per Foot) |
|
- | |||||
| 12 | A3030309 | Gasket (per Foot) |
|
- | |||||
| 15 | C3670805 | Blower Wheel |
|
- | |||||
| 16 | A3030302 | Gasket |
|
- | |||||
| 17 | C8934201 | Plenum Weld |
|
- | |||||
| 18 | A3230302 | Cover-plenum |
|
- | |||||
| 19 | D7365131 | Jumper Wire |
|
- | |||||
| 20 | WPM0104106 | Clip,cord (Replaces: M0104101) |
|
$ 7.35 | |||||
| 21 | WP489349 | Screw (Replaces: M0216515) |
|
Immediately | $ 7.59 | ||||
| 22 | M0370007 | Strain Relief |
|
- | |||||
| 23 | B5674403 | Cord, Power |
|
- | |||||
| 24 | WP90767 | Screw (Replaces: M0216529) |
|
Immediately | $ 7.43 | ||||
| 25 | B5107619 | Gasket |
|
- | |||||
| 26 | C8798801 | Trans Filament |
|
- | |||||
| 27 | B5779401 | Brkt-transformer |
|
- | |||||
| 29 | B8329801 | Kit, Diode |
|
- | |||||
| 30 | D7224903 | Cover-air Duct |
|
- | |||||
| 31 | D7695801 | Chasiss Power Supply |
|
- | |||||
| 32 | A4055401 | Strap-capacitor |
|
- | |||||
| 33 | M0216517 | Screw |
|
- | |||||
| 34 | B5677203 | Terminal Block |
|
- | |||||
| 36 | M0325401 | Bushing,terminal |
|
- | |||||
| 37 | B8373501 | Plate Tc Mtg |
|
- | |||||
| 38 | WP489464 | Screw (Replaces: M0211217) |
|
Immediately | $ 7.54 | ||||
| 39 | D7374901 | Transformer |
|
- | |||||
| 40 | WP487939 | Nut (Replaces: M0282015) |
|
$ 7.76 | |||||
| 41 | B8353202 | Thermal Fuse W/terminals |
|
- | |||||
| 42 | D8547908 | Capacitor-1.00 |
|
- | |||||
| 43 | A4539601 | Pop Rivet |
|
- | |||||
| 44 | M0216531 | Screw |
|
- | |||||
| 45 | A3030303 | Gasket (per Foot) |
|
- | |||||
| 46 | M0218136 | Screw |
|
- | |||||
| 47 | M0229916 | Screw T.c |
|
- | |||||
| 48 | B8320102 | Resistor Assy |
|
- | |||||
| 49 | B5684109 | Protector, Thermal |
|
- | |||||
| 50 | M0118801 | Clip |
|
- | |||||
| 51 | C8945901 | Plate, Relay Mtg |
|
- | |||||
| 55 | M0258015 | Screw |
|
- | |||||
| 56 | M0232012 | Screw |
|
- | |||||
| 57 | M0234117 | Screw |
|
- | |||||
| 59 | C8873901 | Relay K |
|
- | |||||
| 59 | C8873902 | Relay K |
|
- |
