SBDT520SW (BOM: P1185102W W) | The Brick : Appliance Model Lookup

Diagram #	Part Number	Description	Availability	Ships	Price
1	D7788911	Assy,mc Back	Appelez-nous	-
2	10845601	Pan, Drain	Appelez-nous	-
3	M0201216	Screw - Sm	Appelez-nous	-
4	10845302	H.v. Box Shelf-e Ct	Appelez-nous	-
5	10277024	H V Box-e Ct	Appelez-nous	-
6	C8913701	Support, Mc	Appelez-nous	-
7	A3030358	Gasket-foam	Appelez-nous	-
8	10276904	Top, H.v. Box (e-ct)	Appelez-nous	-
9	12992301	Screw, Tf (Replaces: M0231604)			$ 7.32
10	10874601	Clip-cond.	Appelez-nous	-
11	A3189364	Gasket, Foam	Appelez-nous	-
12	B5742604	Blade, Fan	Appelez-nous	-
13	WPW10169124	Grommet, Compressor (Replaces: 10835901)			$ 7.55
14	WPW10339879	Tie (Replaces: M0321202)			$ 8.30
15	10899501	Clamp, Term. Cover	Appelez-nous	-
16	M0221523	Screw, Shldr	Appelez-nous	-
17	10899601	Overload/relay	Appelez-nous	-
18	W10848274	Capacitor (Replaces: 10958301)			$ 185.85
19	10899701	Cover, Terminal	Appelez-nous	-
20	C8982102	Brkt,cond. Mtr	Appelez-nous	-
21	D7846901	Motor-condenser	Appelez-nous	-
22	W10309997	Compressor (220/230 Vac 50hz) (Replaces: 10740321)			$ 583.93
23	M0218118	Screw	Appelez-nous	-
24	10959103	Harness-mc	Appelez-nous	-
25	10845504	Cond. Fn Shrd	Appelez-nous	-
26	WP90767	Screw (Replaces: M0216716)		Immediately	$ 8.25
27	W11245710	Screw, Sm (stnls) (Replaces: M0210417)		Immediately	$ 14.75
28	M0223803	Screw	Appelez-nous	-
29	10883404	Assy, Cond/pan E-ct	Appelez-nous	-
30	WP489128	Screw (Replaces: M0253516)			$ 11.40
31	M0108001	Clamp, Tube	Appelez-nous	-
32	WP22002933	Screw, Sm (Replaces: M0211357)			$ 8.06
33	B5759645	Gasket, Sealing	Appelez-nous	-
34	10129307	Kit, Defrost Timer (230 Vac)	Appelez-nous	-
36	A3030359	Gasket	Appelez-nous	-
37	M0272803	Lock Washer	Appelez-nous	-
