SELECT A DIAGRAM
1 - Freezer Door
2 - Dispenser
3 - Fresh Food Door
4 - Freezer Section
5 - Fresh Food Section
6 - Fresh Food Section
7 - Unit Parts
8 - Icemaker Wr30x0327
SELECT A DIAGRAM
New Model Search:
| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 1 | 49-60007 | Pm Guide Owners Efs |
|
- | |||||
| 1 | 31-51275 | Pm Mini Manual Wiring |
|
- | |||||
| 3 | WR2X8669 | Fastener Tubular |
|
- | |||||
| 6 | WR12X10112 | Tail Handle Sxs Bk |
|
- | |||||
| 7 | WR12X10333 | Handle Sxs |
|
- | |||||
| 9 | WR02X10431 | Dart Clip |
|
- | |||||
| 10 | WR01X10065 | Scr 8-18 Ba Por 5/8 Ss |
|
- | |||||
| 11 | WR38X10108 | Trim Recess Disp Bk |
|
- | |||||
| 14 | WR24X536 | Gasket Door Bk |
|
- | |||||
| 15 | WR17X3119 | Retainer Strip |
|
- | |||||
| 18 | WR17X1169 | Retainer Strip |
|
- | |||||
| 19 | WR77X600 | Door Inner Fz |
|
- | |||||
| 21 | WR17X3946 | Front Door Shelf |
|
- | |||||
| 23 | WR17X3947 | Front Door Shelf |
|
- | |||||
| 24 | WR17X3948 | Front Door Shelf |
|
- | |||||
| 29 | WR23X10114 | Harness Dr Hinge Fz |
|
- | |||||
| 65 | WZ04X0230 | Screw 8-15 A Pa 3/8 Ss |
|
- | |||||
| 75 | WR17X3669 | Grommet Tube Asm |
|
- | |||||
| 76 | WR2X8933 | Sleeve Water Line |
|
- | |||||
| 80 | WG03A00026 | Nut & Union Asm (Replaces: WR2X8545) |
|
$ 15.72 | |||||
| 87 | WZ04X0241 | Scr 8-15 Ab Tr 1/2 Ss |
|
- | |||||
| 98 | WR1K1 | Screw 8-36 T Ihw 3/8 Sn |
|
- | |||||
| 110 | WR2X8989 | Support Twist Bumper |
|
- | |||||
| 121 | WR12X10113 | Tail Handle Sxs Bk |
|
- | |||||
| 134 | WR01X10019 | Scr 6-10 Pl Flp 1/2 S |
|
- | |||||
| 151 | WR1X1554 | Screw 8-18 Ab Ihw 9/16 S |
|
- | |||||
| 152 | WR01A01241 | Scr 8-18 Ab Fltr 5/8 S (Replaces: WR01X10038) |
|
$ 3.57 | |||||
| 180 | WR1X1966 | Screw 6-32 Pl Ihw 3/8 |
|
- | |||||
| 231 | WR1X1987 | Rivet Plastic Wh |
|
- | |||||
| 231 | WR1X2110 | Plug Fastener |
|
- | |||||
| 276 | WR1X1510 | Grommet Scr |
|
- | |||||
| 303 | WD1X1440 | Housing Terminal |
|
- | |||||
| 461 | WZ06X0136 | Scr 8-18 Ab Hxw 1/2 S |
|
- | |||||
| 556 | WH12X497 | Housing Terminal |
|
- | |||||
| 676 | WZ04X0263 | Scr 10-16 Ab Hxw 1/2 |
|
- | |||||
| 690 | WR1X1466 | Scr 8-32 T Hxw 3/8 S |
|
- | |||||
| 782 | WB17X5060 | Terminal Blk Asm (2 Pin) |
|
- | |||||
| 900 | WR78X10195 | Door Foam Asm Fz Bk |
|
- | |||||
| 1458 | WB17X5062 | Terminal Blk Asm (12pin) |
|
- |
