Diagram # Part Number Description Series Availability Ships Price Add to Cart
1 3180451 Harness, Wiring (main Oven) Appelez-nous -
2 4312950 Harness, Wiring (jack Assembly) Appelez-nous -
3 4313003 Harness, Wiring (main Microwave) Appelez-nous -
4 3179937 Harness, Wiring (t/c Meat Probe) Appelez-nous -
5 3147832 Adapter, Terminal Appelez-nous -
6 4313004 Harness, Wire (base Plate) Appelez-nous -
7 4313005 Wire, Jumper Appelez-nous -
8 4312912 Wire, Ground Appelez-nous -
9 3180450 Harness, Wire (microwave Power) Appelez-nous -
10 4313010 Clip, Harness Appelez-nous -
11 4313009 Clip, Harness Appelez-nous -
12 4313008 Clip, Harness Appelez-nous -
13 3179962 Harness, Wire (door Switch) Appelez-nous -
14 3182054 Harness, Wire Temperature Probe Appelez-nous -
15 7111P002-60 Clamp, Wire   (Replaces: 4159037) Appelez-nous -
15 WP112432 Nut, Hex (3)   (Replaces: 112432) Special Order $ 7.77

16 3179668 Standoff, Wireform (2) Appelez-nous -

    View Diagram in Separate Window     Print Icon   Print Part List

Diagram for KEMS378XWH1
