| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 1 | 10871401 | Cap-w Hndl Bot. |
|
- | |||||
| 3 | 10875801 | Clip-handle |
|
- | |||||
| 5 | 10495803 | Hinge, Top (e-ct) |
|
- | |||||
| 6 | 10849401 | Cover W Hinge |
|
- | |||||
| 7 | W11214483 | Screw, Mach (Replaces: M0202321) |
|
Immediately | $ 14.72 | ||||
| 8 | WP8281196 | Screw, Mach (Replaces: M0202336) |
|
Immediately | $ 7.55 | ||||
| 9 | R9800670 | Kit, Screw (Replaces: M0226331) |
|
$ 10.58 | |||||
| 11 | M0232330 | Screw, Spextite |
|
- | |||||
| 12 | 10866001 | Board-lv Pc |
|
- | |||||
| 13 | 10561601 | Assy, Hinge Pin |
|
- | |||||
| 14 | M0272803 | Lock Washer |
|
- | |||||
| 15 | WP67004977 | Bushing, Top (Replaces: C8964401) |
|
$ 8.20 | |||||
| 16 | C8972405 | Stop-w Door |
|
- | |||||
| 17 | D7833201 | Closure, Door (white) |
|
- | |||||
| 18 | D7838401 | Closure, Door (white) |
|
- | |||||
| 19 | 10969202 | Harness-ref Dr Kit |
|
- | |||||
| 20 | WP98165 | Screw, Sm (Replaces: M0211018) |
|
$ 8.57 | |||||
| 21 | M0217204 | Screw |
|
- | |||||
| 22 | M0335411 | Connector-12 Pin |
|
- | |||||
| 23 | 10399501 | Kit,btm Hinge Shim |
|
- | |||||
| 23 | 10399502 | Kit,btm Hinge Shim |
|
- | |||||
| 24 | R0150108 | Assy, Keyboard (white) |
|
- | |||||
| 25 | 10496109 | Bottom Hinge-wh E Ct |
|
- | |||||
| 26 | WP67006715 | Screw (Replaces: M0233847) |
|
$ 7.55 | |||||
| 27 | W11227370 | Screw, Lock Brake Mounting (Replaces: M0220418) |
|
Immediately | $ 14.91 | ||||
| 28 | 10945901 | Insert, W Handle |
|
- | |||||
| 30 | WP98165 | Screw, Sm (Replaces: M0211018) |
|
$ 8.57 | |||||
| 31 | 10860201 | Kit, Bot.hinge Shim |
|
- | |||||
| 32 | B8387701 | Shim, Door Closure |
|
- | |||||
| 32 | B8387702 | Shim, Door Closure |
|
- | |||||
| 34 | 10871301 | Cap-w Hndl Top |
|
- | |||||
| 35 | M0213517 | Screw K |
|
- | |||||
| 37 | 10887903 | Ass`y, Ref Handle |
|
- | |||||
| 37 | 10887906 | Ass`y, Ref Hndl |
|
- |
